| Quantity: | |
|---|---|
CLW
CLW
New condition/Left and Right hand drive/4x2 | |||
Chassis | Brand | Foton | |
Curb weight(kg) | 1840 kg | ||
Wheelbase(mm) | 2700 mm | ||
Dimensions(mm) | 5130*1690*2000 kg | ||
Overhang (front/rear) (mm) | 1185/1245 mm | ||
1385/1280 mm | |||
Approach/Departure angle(°) | 18/9 | ||
Axle Load(kg) | 1600/2600 kg | ||
Max. driving speed(km/h) | 90 km/h | ||
Clutch | Reinforced diaphragm clutch | ||
Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||
Steering Gear | Power steering, hydraulic steering with power assistance | ||
Tire | Number | 6pcs with one spare tire | |
Specifications | 6.00-14 | ||
Gear box | Manual type, 5 Forwards & 1 Reverse | ||
Cab | It can accommodate three people. With Air conditioner | ||
4B1-82C40 | |||
Displacement(ml) | 2156 | ||
Fuel type | Diesel | ||
60 | |||
Euro 2 | |||
Upper | |||
Box | Tank material | Q235 Carbon steel | |
Tank volume(cbm) | 4 CBM | ||
Max. Loading capacity(tons) | 1.5tons | ||
Button thickness(mm) | 4.0 mm | ||
Side plate thickness(mm) | 3.0 mm | ||
New condition/Left and Right hand drive/4x2 | |||
Chassis | Brand | Foton | |
Curb weight(kg) | 1840 kg | ||
Wheelbase(mm) | 2700 mm | ||
Dimensions(mm) | 5130*1690*2000 kg | ||
Overhang (front/rear) (mm) | 1185/1245 mm | ||
1385/1280 mm | |||
Approach/Departure angle(°) | 18/9 | ||
Axle Load(kg) | 1600/2600 kg | ||
Max. driving speed(km/h) | 90 km/h | ||
Clutch | Reinforced diaphragm clutch | ||
Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||
Steering Gear | Power steering, hydraulic steering with power assistance | ||
Tire | Number | 6pcs with one spare tire | |
Specifications | 6.00-14 | ||
Gear box | Manual type, 5 Forwards & 1 Reverse | ||
Cab | It can accommodate three people. With Air conditioner | ||
4B1-82C40 | |||
Displacement(ml) | 2156 | ||
Fuel type | Diesel | ||
60 | |||
Euro 2 | |||
Upper | |||
Box | Tank material | Q235 Carbon steel | |
Tank volume(cbm) | 4 CBM | ||
Max. Loading capacity(tons) | 1.5tons | ||
Button thickness(mm) | 4.0 mm | ||
Side plate thickness(mm) | 3.0 mm | ||
