| Quantity: | |
|---|---|
CLW
| DIMENSIONS | |
| Tare Weight | 19900kg |
| Payload | 6000kg |
| Overall Dimensions | 13000mm * 2500mm * 3980mm |
| Wheelbase | 7900mm + 1300mm |
| Wheel Thread | 1830mm/1830mm |
| SPECIFICATION | |
| Chassis | Heavy duty and extra durability designed I beam; Optional for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Double Middle Flange 6mm and 8mm ; Bottom Flange 16mm,width 140mm. |
| Axle | 2 axles |
| BPW 8 Ton | |
| Hydraulic System | One set of HYVA cylinder |
| Suspension | Heavy duty mechanical suspension |
| Leaf Spring | 10-piece leaf spring. |
| King Pin | JOST brand 2” Bolt-in King Pin |
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear |
| Wheel Rim | 8.25-22.5 wheel rim, 8 pieces |
| Tyre | 11R22.5 tubeless tire with one spare tire, 8 pieces |
| Spare Tire | One set of spare tire including a carrier |
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box |
| Main Configurations | ● Right/Left side P4/P6/P8/P10 LED outdoor full colour display screen ● Left/Right side with advertising rollers ● Rear LED monochrome screen/LED full color screen, size 1280mm *1440 mm ● Internal and external electrical distribution box ● Circulating ventilation and cooling systems ● Omar Silent diesel generator set ● One set industrial computer with control system,sound system ● Waterproof box 2pcs, amplifier 1pc, Control Panel 1pc. ※ With built-in stage, 20m3 extensible ※ Hydraulically Liftable LED Screen, 1.5m ※ Hydraulic Legs * 4 pcs ※ Stretchable Van Body |
Stage Semi Trailer
1. DIP LED encapsulation confirm the high brightness even under strong sunlight
2. Good protection level waterproof IP65, anti-corrosion,oxidation resistance,long life span
3. Long viewing distance, High definition, Good uniformity
4. Brightness can be adjusted automatically according to different surroundings,
5. Can be set to open and close the screen automatically
6. Can be fixed on the wall, by pole support on the street, on top of building, or for stage rental hanging to meet the request of concert stage background, event show, live broadcasting, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, animation etc, connect with PC computer or network, also can remote control with asynchronous system, Wifi control, 3G control.
7. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising etc.
8. P6 P8 P10 type screen is optional.
| DIMENSIONS | |
| Tare Weight | 19900kg |
| Payload | 6000kg |
| Overall Dimensions | 13000mm * 2500mm * 3980mm |
| Wheelbase | 7900mm + 1300mm |
| Wheel Thread | 1830mm/1830mm |
| SPECIFICATION | |
| Chassis | Heavy duty and extra durability designed I beam; Optional for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 14mm,width 140mm; Double Middle Flange 6mm and 8mm ; Bottom Flange 16mm,width 140mm. |
| Axle | 2 axles |
| BPW 8 Ton | |
| Hydraulic System | One set of HYVA cylinder |
| Suspension | Heavy duty mechanical suspension |
| Leaf Spring | 10-piece leaf spring. |
| King Pin | JOST brand 2” Bolt-in King Pin |
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear |
| Wheel Rim | 8.25-22.5 wheel rim, 8 pieces |
| Tyre | 11R22.5 tubeless tire with one spare tire, 8 pieces |
| Spare Tire | One set of spare tire including a carrier |
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box |
| Main Configurations | ● Right/Left side P4/P6/P8/P10 LED outdoor full colour display screen ● Left/Right side with advertising rollers ● Rear LED monochrome screen/LED full color screen, size 1280mm *1440 mm ● Internal and external electrical distribution box ● Circulating ventilation and cooling systems ● Omar Silent diesel generator set ● One set industrial computer with control system,sound system ● Waterproof box 2pcs, amplifier 1pc, Control Panel 1pc. ※ With built-in stage, 20m3 extensible ※ Hydraulically Liftable LED Screen, 1.5m ※ Hydraulic Legs * 4 pcs ※ Stretchable Van Body |
Stage Semi Trailer
1. DIP LED encapsulation confirm the high brightness even under strong sunlight
2. Good protection level waterproof IP65, anti-corrosion,oxidation resistance,long life span
3. Long viewing distance, High definition, Good uniformity
4. Brightness can be adjusted automatically according to different surroundings,
5. Can be set to open and close the screen automatically
6. Can be fixed on the wall, by pole support on the street, on top of building, or for stage rental hanging to meet the request of concert stage background, event show, live broadcasting, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, animation etc, connect with PC computer or network, also can remote control with asynchronous system, Wifi control, 3G control.
7. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising etc.
8. P6 P8 P10 type screen is optional.
