CLW53100
Foton Donfeng ISUZU HOWO
chemical tanker truck information
1.According to the different transport medium, the chemical liquid tank truck can be divided into :
Hydrochloric acid transport truck, sulfuric acid truck,
hydrofluoric acid transport truck,, formic acid transport truck,
acetic acid truck,hydrogen peroxide truck,phosphate truck,
ammonia truck, sodium hydroxide solution truck,potassium transport truck,
sodium hypochlorite truck,formaldehyde truck,ethanol truck,
toluene truck, xylene truck,isopropanol truck, dimethylamine easy truck,
naohtha transport truck and so on .
2.Tank material choose according the requirement :
Carbon steel , carbon steel lined with plastic , stainless steel , plastic , aluminum
3.Tank body shape : oval, square round, round
4. chemical pumps :high quality chemical liquid pumps
5. Functionality: can be independent or subwarehouse , load different chemicals, liquid goods.
3 axles chemical tanker semi trailer specifications
[main technical data] | |||
Products Brand | CLW | ||
Products name | Corrosive substances tank transport trailer | Products Model | CLW9401GFWB |
Total Mass (Kg) | 40000 | Tank Volume(m3) | 17.8 |
Ratings Load(Kg) | 31340 | Overall dimension(mm) | 9900×2500×3500 |
Curb weight (Kg) | 8660 | Medium | Sulfuric acid |
Tank overall dimension D*L(mm) | Φ1730×9400 (Long straight section 8700 ) | Density | 1.84 T/m³ |
Protect material | Q235B carbon steel | ABS model | CM2XL-4S/2K(4S/2M) |
A/D angle(°) | -/20 | F/R hanging (mm) | -/1480 |
Axles Number | 3 | Wheelbase(mm) | 4600+1310+1310 |
Wheel load(Kg) | -/24000(fitted triaxial) | ||
[chassis specification] | |||
Dimension (mm) | 9900×2500×3500 | Tire Number | 12 |
A/D angle(°) | -/20 | Tire Size | 11.00R20 12PR, 12R22.5 12PR |
Number of leaf spring | -/8/8/8,-/9/9/9 | Front track(mm) | - |
Rear track(mm) | 1840/1840/1840 |
Company Information
ChengLi Special Automobile Co., Ltd., which is appointed by the Development and Reform Commission of China, is a professional manufacturer of special automobiles for landscaping, petrochemical, and environment cleanness. Our company has independent export authority, and has a lot of overseas clients. Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation.
More than 15 years' experience as a manufacturer
Competitive Price and Excellent Quality
CCC, ISO, BV, ASME certification
Perfect after-sale service
Trucks covering more than 50 countries and regions
800 kinds of trucks and trailers
100 Senior welder and 15 senior engineers
Good cooperation with 30% regular customers
Annual production value topped 240,000,000 US dollars per year
Customized Truck & Trailer Solutions to Meet Your Requirements
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck / Blasting equipment transporter/ Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
