FOTON 10 Tons Bulk Feed Truck with Discharge Auger and Hydraulic System
Main Technical Parameter |
Product Name | Bulk Feed Transport Truck | Gross Vehicle Weight (kg) | 15600 |
Rated Payload (kg) | 7000 | Curb Weight (kg) | 8405 |
Tank Capacity(L) | 15,000 | Cab Allowed Persons | 3 |
Axle No. | 2 | Wheelbase (mm) | 5000 |
Loading Speed(kg/min) | 400-550 | Loading system rotation angle | ±180 degree |
Loading system elevation angle | 60 degree |
|
|
Chassis Technical Parameter |
Chassis Model | BJ1163VKPHK-A | Chassis Name | Truck Chassis |
Chassis Brand | FOTON | Manufacturer | Bejing FOTON Automobile Co.,Ltd |
Overall Dimension (mm) | 8500×2360×2830 | Tyre No. | 6 with 1 spare tyre |
App./ Dep. Angle(º) | 21/14 | Tyre Spec. | 8.25-20 |
Leaf Spring No. | 9/12+9 | Front Track (mm) | 1935 |
Fuel Type | Diesel | Rear Track (mm) | 1800 |
Drive Type | 4x 2 | Brake System | Air brake |
Clutch | Φ395mm diaphragm-spring | Gear Box | 6 speed forward and 1 reverse |
Engine Technical Parameter |
Engine Model | YC6J180-42 | Emission Standard | Euro IV |
Displacement ( mL ) | 6500 | Power (KW) | 180HP/132KW |
