ISUZU VC 46 350 HP Prime Mover TRACTOR HEAD for semi trailer

Quantity:
  • QL4251UZK

ISUZU VC46 Prime Mover 10 Wheeler 6X4 350HP Trailer Tractor Head 40ton



Product Description



ISUZU VC46 Prime Mover 10 Wheeler 6X4 350HP Trailer Tractor Head 40ton



1) haulage capacity of VC46 Prime Mover:30ton,30mt,40ton,40mt

2) Engine of VC46 Prime Mover:weichai 6UZ1-TCG40, 350hp  EURO 4

3) Cabin of VC46 Prime Mover:H7 new model cabin,high proof with A/C





Specifications of  ISUZU VC46 Prime Mover 10 Wheeler 6X4 350HP Trailer Tractor Head 40ton



ISUZU VC 46 TRACTOR HEAD

ISUZU VC 46 TRACTOR HEAD

Item No.

Parameters

Overall Dimension

7000*2490*3580 mm

Drive model

6X4, new condition , LHD , 2019 YEAR

Cabin

ISUZU standard cabin, mp3 and AC included. 3 Person(2 seats+1 bed)

Gross Vehicle Weight

48 200kg

Curb Weight

8 200 kg

Loading Capacity

40 000 KG

Wheel Base

3425+1300 mm

Front axle/rear axle loading

7500/18000/18000 kg

Front/rear Overhang

1370/905 mm

Front/rear Tread

2060/1855/1855 mm

Approach/Departure Angle

17/42  degree

Max. driving speed

90 km/h

Max. Gradebility

34 %

Min. Ground clearance

278 mm

Fuel consumption

29 liter/100 km

Engine

ISUZU, 6UZ1-TCG40 , Diesel Engine, Four Stroke, electronic control, 6 Cylinder in line with water cooling, turbo-charging and inter-cooling.

Engine horsepower

350 HP(257 kw) , Euro4 ,

Max. Torque:

1422 N.M 1400 r/min

Specific fuel consumption

184 g/kwh

Engine oil filling quantity

191

Displacement

9.8  L(Diesel)

Max Driving Speed

90 km/h

Steering

Powering steering, LHD

Gear Box

FAST 9JS150T-A , Manual, 9 Forward Gear, 1 Backward Gear

Ratio: 12.57, 7.47, 5.28, 3.82, 2.79, 1.95, 1.38, 1.00, 0.73, 13.14(R1).

Propeller shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Brakes

Service brake: dual circuit compressed air brake; Parking brake(Emergency brake): spring energy, compressed air operating on front shaft and rear wheels. Auxiliary brake: Engine exhaust brake

Wheels & Tyres

Tire: 11.00-20 16PR;

Saddle

3.5 inch or 2 inch for selection before production

Driver cabin

Standard cab, with two seats, 1 bed , 2 arm windscreen viper system with three speeds;  Damped adjustable drivers seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn;

24 V USB, With transverse stabilizer, with 4 point support fully floating suspension+shock absorber

Electrics

Operating voltage: 24 V, Negative grounded

Starter: 24 V, 5.4KW.

Alternator: 3 phase, 28v, 1500W.

Batteries: 2x12 v, 165 Ah.

Cigar-lighter, horn, headlamp, fog lights, brake lights, indicators and reverse light,

Instrument panel

Active check central controllor with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators. Compressed air pressure, coolant temperature, engine oil pressure and battery charging.

IMG_20180824_110308

QQ图片20181206172631DSC00758QQ图片20180918140318

Our Service
  • Quick feedback to solve your questions

  • Professional engineering and production team

  • Related Accessories and spare parts offered,no future worries

  • Regular customer after-sale visiting

  • Free technical staff training and guidance

  • Reasonable price and good quality

  • Quick delivery and shipment

  • Email: info@clwvehicle.com



FAQ



Q1: What kinds of LPG products I can order from your company?


A: CHENGLI SPECIAL AUTOMOBILE CO.,LTD(CLW GROUP) specialize in producing 5CBM to 200CBM LPG above ground storage tanker, 5CBM to 120CBM LPG underground storage tank, 5CBM to 38.5CBM LPG tank truck, 5CBM to 25.5CBM LPG dispenser truck/LPG bobtail truck, 40CBM to 61.9CBM LPG semi trailer and 5CBM to 50CBM LPG Skid Station/LPG mobile filling station etc. Please feel free to contact us for details.



Q2: What is your production standard of LPG products? Can you manufacture your products under ASME standard?


A: Usually our LPG products adopts GB-150/China standard, there ASME standard for optional. Yes, we can do ASME standard and our ASME standard as per DIV 01 SEC VIII.



Q3: Have you supplied LPG products to any renowned companies?


A: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks and semi trailer for them with different sizes,such as MRS, MATRIX,AARANO,NIPCO,LAKEGAS, ENCO and other oil and gas company...The biggest size tank we ever provided is 200m3 LPG storage tanks,.



Q4: What about warranty?


A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

LPG tankers warranty is 10-15  years from the dete of delivery.  All the tank can work more than 15 years at least and need to inspect it when the year reach 10 years.



Q5: Where is your factory? How far from Hongkong, Shanghai or guanGzhou to your factory?


A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing, Hongkong, Shanghai or Guangzhou city, or For the fast trains, 4.5 hours high speed train from hongkong, 4 hours from guangzhou, 4 hours from shanghai. We welcome you to visit us for factory inspection at any time.
