Item | Unit | Parameter | |
Chassis brand | Dong Feng | ||
Oil consumption/km. | L | 6 | |
Fuel type | Diesel | ||
Emission standard | Euro 3 | ||
Horse Power | 95HP | ||
Fact height | M | 12m | |
Maximum operation radius | 5.7 | ||
Gross vehicle weight | Kg | approx4325 | |
Mass in working order | approx4000 | ||
Wheel base | Mm | 3300 | |
F/R track base | 1506/1466mm | ||
Approach/departure angle | ° | 19/11° | |
Max speed | km/h | 95 | |
Tire specification | 7.00-16 | Engine type | CY4102 |
Traction system | 4*2 | Transmission | 5-speed with over drive |
Number of axles | 2 | Electric system | 24v |
Operation control system | Electrically hydraulic control | Allowable passengers in Cab | 2+3 |
Engine | Environmentally diesel engine with 4 cylinders and water cool | ||
Equipment | 1. Max operation height：12m 2. Max operation radius≧5.7m 3. Max working platform height≧9 m 4. Working platform rating loading=200kg, 5. Working platform rating allowable passengers=2 6. Working platform dimension:1100*570*1000mm 7. 360°turning(left or right),4 H-shape legs 8.The cage be operated both in the air and on the earth 9. The cabin can be equipped with Air conditioner (optional) | ||
