Drive Model | 4x2 | ||
Vehicle Main Dimensions | Dimensions(L x W x H)mm | 7420X2300X2540 | |
Wheel base (mm) | 3800 | ||
Overhang (front/rear) (mm) | 1180/2440 | ||
Wheel track (front/rear) (mm) | 1835/1640 | ||
Approach/Departure angle(°) | 20/10 | ||
Weight in KGS | Curb Weight | 5495 | |
GVW. | 7490 | ||
Max. driving speed(km/h) | 90 | ||
Engine | Model | CY4102 | |
Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
Horse Power(HP) | 120HP | ||
Emission standard | Euro III | ||
Gearbox | 5 forwards & 1 reverse | ||
Clutch | Reinforced diaphragm clutch | ||
Steering Gear | Power steering, hydraulic steering with power assistance | ||
Fuel tank (L) | 180 | ||
Tire | 7.50R16 , 6pcs + 1 spare tire | ||
Brakes | Exhaust brake | ||
UPPER | |||
Platform Organ | LXW（mm） | 5400x2100 | |
Platform power stroke(mm) | 2680 | ||
Min angle(°) | 7.6 | ||
Max lifting capacity(kg) | 4000 | ||
Winch rating pulling capacity(kg) | 4000 | ||
Length of steel(m) | 21 | ||
Hoisting Organ | Max under-hoisting capacity(mm) | 1300 | |
Rating under-hoisting capacity(mm) | 1005 | ||
Fully extended max under-hoisting capacity(mm) | 700 | ||
Rating under-pulling capacity(kg) | 6400 | ||
With auxiliary wheels, hooks, bundling belt, automatic sliding plate; Caution light, air condition are optional. | |||
