| Quantity: | |
|---|---|
CLW
| Cabin | Driving type 4x2 | |
| With A/C ,with two seats, 70°hydraulically tillable to the front. | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 5885*2000*2885 |
| Wheel base (mm) | 3360 | |
| Wheel track (front/rear) (mm) | 1530/1425 | |
| Approach/Departure angle(°) | 22/21 | |
| Weight in KGS | Tare Weight | 4495 |
| payload | 4000 | |
| Front axles loading capacity | 1x3000 | |
| Rear axles loading capacity | 1x5200 | |
| Max. driving speed（km/h） | 90 | |
| Engine | Model | FOTON ISUZU, BJ493ZLQ1 |
| Horse Power（HP) | 108 | |
| Emission standard | Euro II | |
| Gearbox | WLY6T46 , Manual type, 6 forwards & 1 reverse | |
| Tire | 7.00R16 *6 pcs with one spare | |
| Main Configurations | ● Right/Left side P4/P6/P8/P10 LED outdoor full colour display screen ● Left/Right side with advertising rollers ● Rear LED monochrome screen,size 1280mm *1440 mm ● Internal and external electrical distribution box ● Circulating ventilation and cooling systems ● Omar Silent diesel generator set ● One set industrial computer with control system,sound system ● Waterproof box 2pcs, amplifier 1pc, Control Panel 1pc. ※ With built-in stage ※ Hydraulically Liftable LED Screen | |
LED Advertising Truck
1. DIP LED encapsulation confirm the high brightness even under strong sunlight
2. Good protection level waterproof IP65, anti-corrosion,oxidation resistance,long life span
3. Long viewing distance, High definition, Good uniformity
4. Brightness can be adjusted automatically according to different surroundings,
5. Can be set to open and close the screen automatically
6. Can be fixed on the wall, by pole support on the street, on top of building, or for stage rental hanging to meet the request of concert stage background, event show, live broadcasting, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, animation etc, connect with PC computer or network, also can remote control with asynchronous system, Wifi control, 3G control.
7. Widely used for outdoor commercial advertising, stage rental, traffic advertising, mobile truck advertising, sports stadium advertising etc.
8. P6 P8 P10 type screen is optional.
9. We can provide Dongfeng, Foton, FAW, JAC, JMC, SINOTRUK HOWO, or any other Chinese truck chassis brand.
