30T 50T 80T heavy duty Low flatbed trailer truck with FOTON HOWO ISUZU tractor
Specification for 30T 50T 80T heavy duty Low flatbed trailer truck with FOTON HOWO ISUZU tractor
30T 50T 80T heavy duty Low flatbed trailer truck with FOTON HOWO ISUZU tractor | |
DIMENSIONS | |
Tare weight | 10000kg |
Size | 13000mm*2500mm*1250mm |
Payload | 60T |
Main beam | Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 20mm,width140mm;Middle Flange 14mm height 500mm;bottom flange20mm,width 140mm |
Side beam | 25# channel steel(Q235) |
Cross member | 16# channel steel(Q235) |
Floor | 5mm checkered plate |
Side wall | No |
Front board | No |
Axle | 3 axle FUWA brand 13T |
Suspension | Mechanical suspension American type local brand |
Leaf spring | Leaf spring 10pcs*90*13mm |
Tire | 12R22.5-18pr double star brand 12pcs |
Wheel rim | 9.0-22.5 better brand 12pcs |
Kingpin | JOST brand 2” weld king pin |
Landing gear | JOST brand two-speed, manual operating ,heavy duty landing gear 28T |
Ladder | Mechanical ladder |
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
ABS | Optional |
Lights | LED 8 side lights and 2 rear lights 2 width lamp |
Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
Accessories | One standard tool box,one spare tire carrier,one crank,one shaft headwrench,four side light,two rear light |
Date of delivery | 40 workdays after we received 30% of contract value T/T down payment |
If you have any requirement, please feel free to contact us!
