Item No. | Parameters |
Overall Dimension | 7600x2500x3350 mm |
Driving Model | Left hand drive/ With A/C. |
Gross Vehicle Weight | 11495 kg |
Curb Weight | 8500kg |
Capacity | 8000 kg |
Wheel Base | 3950 mm |
Front/rear Tread | 1900/1800mm |
Approach/Departure Angle | 33/13 degree |
Front Axle | 4195kg |
Rear Axle | 7300kg |
Engine | B170 33,4-stroke direct injection,6-cylinder in-line with water cooling,turbo-charging and inner cooling |
Engine horsepower | 170 HP Euro III |
Displacement | 5900mL (Diesel) |
Max Driving Speed | 90 km/h |
Cabin | 2~3 Passenger allowed,with Air Conditioner |
Tire | 9R22.5 (7 pieces) |
Garbage Box | 6 speed. |
Volume | 10cbm |
Box Material | Q235 carbon steel |
Box Thickness | Side 4 mm, and bottom 5mm. |
Equipment | 1.Equipped with hermetic dustbin, hydraulic system and operating system 2.Automatic compress and uninstall, sewage can be collected by the dump tank. 3.Cycling time＜14--18s |
Painting and Logo | As required |
Main Products:
1.Water Truck
2.Insulation Truck and Milk Truck
3.Sewage Suction Truck
4.Garbage Truck
5.Manlift Truck/Aerial Platform Truck
6.Truck with Crane
7.Fuel Truck/
8.Chemical Truck
9.Bulk Cement Truck
10.Concrete Mixer Truck
11.Fire Truck
12.Dump Truck
13.Van Truck/Refrigerated Truck
14.Wrecker/Tow Truck
15.Flatbed Truck/Low Bed
16.Tractor
17.LPG Truck
18.Trailers
