Item No. | Parameters |
Overall Dimension | 7600x2500x3350 mm |
Driving Model | Left hand drive/ With A/C. |
Gross Vehicle Weight | 11495 kg |
Curb Weight | 8500kg |
Capacity | 8000 kg |
Wheel Base | 3950 mm |
Front/rear Tread | 1900/1800mm |
Approach/Departure Angle | 33/13 degree |
Front Axle | 4195kg |
Rear Axle | 7300kg |
Engine | B170 33,4-stroke direct injection,6-cylinder in-line with water cooling,turbo-charging and inner cooling |
Engine horsepower | 170 HP Euro III |
Displacement | 5900mL (Diesel) |
Max Driving Speed | 90 km/h |
Cabin | 2~3 Passenger allowed,with Air Conditioner |
Tire | 9R22.5 (7 pieces) |
Garbage Box | 6 speed. |
Volume | 10cbm |
Box Material | Q235 carbon steel |
Box Thickness | Side 4 mm, and bottom 5mm. |
Equipment | 1.Equipped with hermetic dustbin, hydraulic system and operating system 2.Automatic compress and uninstall, sewage can be collected by the dump tank. 3.Cycling time<14--18s |
Painting and Logo | As required |
Main Products:
1.Water Truck
2.Insulation Truck and Milk Truck
3.Sewage Suction Truck
4.Garbage Truck
5.Manlift Truck/Aerial Platform Truck
6.Truck with Crane
7.Fuel Truck/
8.Chemical Truck
9.Bulk Cement Truck
10.Concrete Mixer Truck
11.Fire Truck
12.Dump Truck
13.Van Truck/Refrigerated Truck
14.Wrecker/Tow Truck
15.Flatbed Truck/Low Bed
16.Tractor
17.LPG Truck
18.Trailers
Item No. | Parameters |
Overall Dimension | 7600x2500x3350 mm |
Driving Model | Left hand drive/ With A/C. |
Gross Vehicle Weight | 11495 kg |
Curb Weight | 8500kg |
Capacity | 8000 kg |
Wheel Base | 3950 mm |
Front/rear Tread | 1900/1800mm |
Approach/Departure Angle | 33/13 degree |
Front Axle | 4195kg |
Rear Axle | 7300kg |
Engine | B170 33,4-stroke direct injection,6-cylinder in-line with water cooling,turbo-charging and inner cooling |
Engine horsepower | 170 HP Euro III |
Displacement | 5900mL (Diesel) |
Max Driving Speed | 90 km/h |
Cabin | 2~3 Passenger allowed,with Air Conditioner |
Tire | 9R22.5 (7 pieces) |
Garbage Box | 6 speed. |
Volume | 10cbm |
Box Material | Q235 carbon steel |
Box Thickness | Side 4 mm, and bottom 5mm. |
Equipment | 1.Equipped with hermetic dustbin, hydraulic system and operating system 2.Automatic compress and uninstall, sewage can be collected by the dump tank. 3.Cycling time<14--18s |
Painting and Logo | As required |
Main Products:
1.Water Truck
2.Insulation Truck and Milk Truck
3.Sewage Suction Truck
4.Garbage Truck
5.Manlift Truck/Aerial Platform Truck
6.Truck with Crane
7.Fuel Truck/
8.Chemical Truck
9.Bulk Cement Truck
10.Concrete Mixer Truck
11.Fire Truck
12.Dump Truck
13.Van Truck/Refrigerated Truck
14.Wrecker/Tow Truck
15.Flatbed Truck/Low Bed
16.Tractor
17.LPG Truck
18.Trailers
Company Profile
Chengli Special Automobile Co., Ltd which is appointed by Ministry of Industry and Information Technology of China, is a manufacturer producing all kinds of special trucks and semi-trailer.
1.Our company cooperates with famous chassis manufacturers, such as DONGFENG, FAW, SINOTRUK, FORLAND and etc.
2.We can produce more than 300 kinds of special trucks, semi-trailer and storage tanks. Chengli take customer's satisfaction as the top requirement.
3.All of the trucks and semi-trailer sell to Africa, South-east Asia, Australia and other place. And receive good reputation.
We serve the best service for each client.
Company Profile
Chengli Special Automobile Co., Ltd which is appointed by Ministry of Industry and Information Technology of China, is a manufacturer producing all kinds of special trucks and semi-trailer.
1.Our company cooperates with famous chassis manufacturers, such as DONGFENG, FAW, SINOTRUK, FORLAND and etc.
2.We can produce more than 300 kinds of special trucks, semi-trailer and storage tanks. Chengli take customer's satisfaction as the top requirement.
3.All of the trucks and semi-trailer sell to Africa, South-east Asia, Australia and other place. And receive good reputation.
We serve the best service for each client.
