SINOTRUK HOWO 4 CBM Rear Compactor Garbage truck | |
Item No. | Parameters |
Overall Dimension | 6240*2050*2570 mm |
Country of Original | China |
Drive model | 4x2, new condition , RHD |
Gross Vehicle Weight | 7350 kg |
Curb Weight | 5365 kg |
Loading Volume | 4 CBM |
Wheel Base | 3360 mm |
Front/rear Overhang | 1032/2138 mm |
Front/rear Tread | 1506/1466 mm |
Approach/Departure Angle | 19/10 degree |
Engine | YUNEI Engine,YN4102QBZL ,Standard type engine, Diesel Engine, Four Stroke, 4 Cylinder in line. |
Engine horsepower | 116 HP Euro 2 |
Max Driving Speed | 90 km/h |
Gear Box | 5 Forward Gear, 1 Backward Gear |
Tire | 7.00R16, 7 pieces (with 1 spare tire.) |
Volume Capacity(Garbage) | 4 CBM |
Specification of 4cbm Box of Compactor Garbage Truck | ||
Garbage Bin | Capacity | 4 CBM |
Size (length x width x height) | 4900x2050x2150 mm or as designation | |
Thickness | Side 4mm, Bottom 5mm | |
Material | Q235 carbon steel | |
Design | Whole unit with Leakage Proof Design | |
Recovery water tank | 200L | |
Filling parts volume | 600L | |
Filling time | 8-10s | |
Compression cycling time | 30s | |
Discharging type | Push and self-discharging | |
Discharging time | 30s | |
Hydraulic system pressure | 16Mpa, 160Bar | |
Control type | Electric control with manual control | |
Plat Form | 2 side for 2 worker for foot transport | |
Ways of Loading | Rear Loading with optional Bucket Lifting Style | |
