CLW DONGFENG 4*2 6 Tons Water Tank Fire Fighting Truck

Overall Dimension :8150*2500*3450 mm
Drive model: 4x2, new condition , RHD
GVW :16000 kg
Curb Weight:9750 kg
Loading weight 6150 kg
Wheel Base:4500 mm
Front/rear Overhang:1440/2095 mm
Front/rear Tread:1900/1800mm
Approach/Departure Angle: 19/13 degree
Engine:Cummins ENGINE B19033, Diesel Engine, Four Stroke, 6 Cylinder in line.
Engine horsepower :190 HP Euro 3
Gear Box : 6 Forward Gear, 1 Backward Gear
Tire: 10.00R20 ,6 pieces with 1 spare tire.
Tank parameter
Water volume(m³):6 CBM
Material of the tank :carbon steel
Type of fire pump: Centrifugal pump
Fire fighting pump suction depth :7m

Quantity:
  • clw0011
  • clw

CLW DONGFENG 4*2 6 Tons water tank fire fighting truck

微信图片_20181127195324

CLW DONGFENG 4*2 6 Tons water tank fire fighting truck

Item No.

Parameters

Overall Dimension

8150*2500*3450 mm

Drive model

4x2, new condition , RHD

GVW

16000 kg

Curb Weight

9750 kg

Loading weight

6150 kg

Wheel Base

4500 mm

Front/rear Overhang

1440/2095 mm

Front/rear Tread

1900/1800mm

Approach/Departure Angle

19/13 degree

Engine

Cummins ENGINE B19033, Diesel Engine, Four Stroke,

6 Cylinder in line.

Engine horsepower

190 HP Euro 3

Displacement

5.9 L(Diesel)

Full loading Fuel Consumption Rate

140 G/KW.H

Max Driving Speed

85 km/h

Gear Box

6 Forward Gear, 1 Backward Gear

Tire

10.00R20 ,6 pieces with 1 spare tire.

Tank parameter

Water volume

6 CBM

Material of the tank

Carbon steel

Type of fire pump

Centrifugal pump

Fire fighting pump suction depth

7m

Standard equipment

Middle and low pressure pump CB10/40

Flow : 40L/S;

Pump Pressure: 1.0 MPa;

Pipes pressure: 1.0 MPa

Fire Distance(water): ≧60m

Fire fighting pump suction time:<35s

Delivery outlet(B/S type) :65mm(21/2)

Rotation angle of fire fighting turret nozzle:360degree

Company Introduction:


ChengLi Special Automobile Co., Ltd., which is appointed by the Development and Reform Commission of China, is a professional manufacturer of special automobiles for landscaping, petrochemical, and environment cleanness. Our company has independent export authority, and has a lot of overseas clients. Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation.

l  More than 15 years' experience as a manufacturer

l  Competitive Price and Excellent Quality

l  CCC, ISO, BV, ASME certification

l  Perfect after-sale service

l  Trucks covering more than 50 countries and regions

l  800 kinds of trucks and trailers

l  100 Senior welder and 15 senior engineers

l  Good cooperation with 30% regular customers

l  Annual production value topped 240,000,000 US dollars per year
