SINOTRUK HOWO 4X2 6m3 98hp Water And Foam Fire Fighting Truck

Overall Dimension :8150*2500*3450 mm Drive model: 4x2, new condition , RHD GVW :16000 kg Curb Weight:9750 kg Loading weight 6150 kg Wheel Base:4500 mm Front/rear Overhang:1440/2095 mm Front/rear Tread:1900/1800mm Approach/Departure Angle: 19/13 degree Engine:Cummins ENGINE B19033, Diesel Engine, Four Stroke, 6 Cylinder in line. Engine horsepower :190 HP Euro 3 Gear Box : 6 Forward Gear, 1 Backward Gear Tire: 10.00R20 ,6 pieces with 1 spare tire. Tank parameter Water volume(m³):6 CBM Material of the tank :carbon steel Type of fire pump: Centrifugal pump Fire fighting pump suction depth :7m
  • clw0011

  • clw

SINOTRUK HOWO 4X2 6m3 98hp Water And Foam Fire Fighting Truck

fire truck

Technical parameter

SINOTRUK HOWO 4X2 6m3 98hp Water And Foam Fire Fighting Truck

Item No.


Overall Dimension

8150*2500*3450 mm

Drive model

4x2, new condition


16000 kg

Curb Weight

9750 kg

Loading weight

6150 kg

Wheel Base

4500 mm

Front/rear Overhang

1440/2095 mm

Front/rear Tread


Approach/Departure Angle

19/13 degree

Engine horsepower

190 HP Euro 3


5.9 L(Diesel)

Full loading Fuel Consumption Rate

140 G/KW.H

Max Driving Speed

85 km/h

Gear Box

6 Forward Gear, 1 Backward Gear


10.00R20 ,6 pieces with 1 spare tire.

Tank parameter

Water volume


Material of the tank

Carbon steel

Type of fire pump

Centrifugal pump

Fire fighting pump suction depth


Standard equipment

Middle and low pressure pump CB10/40

Flow : 40L/S;

Pump Pressure: 1.0 MPa;

Pipes pressure: 1.0 MPa

Fire Distance(water): ≧60m

Fire fighting pump suction time:<35s

Delivery outlet(B/S type) :65mm(21/2)

Rotation angle of fire fighting turret nozzle:360degree
