CLW9360GYQ
CLW
| Specification | |||||||||||
| Items | Data | Items | Data | ||||||||
| Semi trailer | Tank | ||||||||||
| Curb weight | 15300 kg | Design pressure | 1.61Mpa | ||||||||
| Payload | 20832kg | Design temperature | 50 ℃ | ||||||||
| G.V.W. | 36132 kg | Filling medium | LPG | ||||||||
| Capacity | 49.6 m3 | Tank material | Q345R Carbon Steel | ||||||||
| Wheel Base | 6800+1310+1310mm | Corrosion allowa | 1.0 mm | ||||||||
| nce | |||||||||||
| External Dimensions | 12740*2480*3800mm | Hydraulic test pressure | 2.22Mpa | ||||||||
| Full load | Fifth wheel load | 16000Kg | Thickness of material | Tank | 12 mm | ||||||
| Rear axle load | 24000kg | Cover | 12 mm ellipse | ||||||||
| Design the limited velocity | Straight road | 80 Km/h | Vessel’s sort | The third kind | |||||||
| Turning | 20 Km/h | Service year | 10 years | ||||||||
| Emergence cutting valve | Safe valve | ||||||||||
| Nominal pressure | PN2.5Mpa | Model | Inner full lift | ||||||||
| Nominal diameter | Gas phase | DN 25mm | Nominal pressure | PN2.5 Mpa | |||||||
| Liquid phase | DN 50mm | Nominal diameter | DN80mm | ||||||||
| Operation way | Mechanical type | set-pressure | 1.77 Mpa | ||||||||
| Closing time | ≤10 Sec | Rated relieving pressure | <1.93 Mpa | ||||||||
| Melt switch temperature | 70±5℃ | ||||||||||
| Level meter | Inlet and outlet | ||||||||||
| Model | Handle Rotary type | Model | Quick tie-in | ||||||||
| Nominal pressure | PN2.5Mpa | Nominal diameter | Gas phase | DN25mm | |||||||
| Surveying range | 50~2300mm | Liquid phase | DN50mm | ||||||||
| Precision | 2.5 Grade | ||||||||||
| Standard configuration | 3 axles with BPW bridge (13T)、air suspension、 12R22.5 12PR(13 pcs), JOST king pin、JOST leg（25T）、mechanic liquid level meters、double pressure meter、double thermometer、double emergency cutting valve 、four ball valve、double safe valve、two tool boxes, single outlet ,double loading and unloading system、aluminum mudguard protection、2 sets 9kg fire extinguishers type ABC、1 set 2kg fire extinguisher type CO2、3 sets danger sign plate、2 sets orange numbered plate、flow meter with printer | ||||||||||
