Top safety Gas Cylinder 20 cbm Liqid ammonia Tank
Product features
1,Liqid ammonia Tank is the stationary vessel to store liquid Ammonia and widely used in various industries. We can provide different capacity and standard storage tank.
2,It is designed according to new regulation with high safety performance and long durable time.
3,Optimize the Liqid ammonia Tank according to the tank capacity to make the tank of best structure and reduce the material.
4,The tightness between the valve and the flange is good to enhance the safety performance.
5,The pressure gauge adopts flange connection and is not easy to damage when replacing.
Item | Parameter |
Size(inner diameter*tank thickness*length) | 2000*14*6702 |
GVW(kg) | 6400 |
Filling weight(kg) | 9880 |
Type of vessel | The third kind |
Design pressure | 2.16MPa |
Design temperature | 50ºC |
Filling medium | Ammonia Gas |
Corrosion allowance | 2.0mm |
Volume | 20 CBM |
Thermal treatment | The entirety |
Density | 520kg/m³ |
Material of the tank | Q345R |
Hydraulic test pressure | 2.70 M Pa |
Shell thickness | 16mm |
| Endplate thickness | 16mm |
Service Time | 15 years |
Company Information
Chengli Special Automobile Co., Ltd., was established in 2004. We are a professional manufacturer and exporter which is concerned with the design, development and production of more than 300 kinds of trucks, such as LPG storage tank, Water truck,Fecal sucktion truck,Garbage truck,Refuse compactor,Sewage sucktion truck,Fuel tank,High-altitude operation truck,Truck with crane,Dump truck,Instructional truck,Van truck, Semi-trailer,Fire engine,Spares,Refrigerator truck,Water wagon,Tractor, High-altitude water truck,Bulk cement truck,Chemical liquid truck,Concrete mixer truck,ect.
All of our products reach the international quality standards and are greatly appreciated in a variety of markets around the world.
